The 26/35kV Unarmored Copper Power Cable is in stock and ready to ship at MiningGear Co. Buy the 26/35kV Unarmored Copper Power Cable at the best rate possible, every order includes a free compatible PSU, secure bank-wire or crypto payment, and fully tracked, insured worldwide DDP shipping, warehouse to your door in 80+ countries.
Application
The cable are mainly used for power distribution in power stations, industrial installation. Apply to shafts, water and soil, able to bear the larger positive pressure.
Characteristics
Rated voltage: 26 / 35 kV
Maximum Conductor Temperature: under normal (90℃), emergency (130℃) or short circuit no more than 5 s (250℃) conditions.
Min. Ambient Temp. 0℃, after installation and only when cable is in a fixed position
Min. Bending Radius: 15 x cable O.D for single core
12 x cable O.D for multi core
① Conductor: Compact stranded copper conductor, Cl.2 as per IEC 60228
② Conductor Screen: Semi-conductor
③ Insulation: XLPE (cross-linked polyethylene) rated at 90OC
④ Insulation Screen: Semi-conductor
⑤ Screen: Copper tape
⑥ Inner covering : PVC
⑦ Armoring: Aluminum wire, 1 core
Galvanized steel wire, 3 cores
⑧ Sheath: PVC or FR-PVC type ST2 to IEC 60502, black
Standards
International: IEC 60502, IEC 60228
China: GB/T 12706
Other standards such as BS, DIN and ICEA upon request
Certificates
CE, RoHS, CCC and more others at request
Specifications
| Nom. Cross-section of conductor | Insulation Thickness | Inner Covering Thickness | Dia. Of Armor Wire |
Sheath Thickness | Approx. O.D. | Approx Weight | Max. D.C. Resistance of Conductor (20°C) | Test Voltage A.C | Current Rating | |
| mm2 | mm | mm | mm | mm | mm | kg/km | Ω/km | kV/5min | In air(A) | In soil(A) |
| 1×50 | 10.5 | 1.3 | 2.5 | 2.4 | 47 | 4049 | 0.387 | 91 | 220 | 215 |
| 1×70 | 10.5 | 1.3 | 2.5 | 2.5 | 49 | 4433 | 0.268 | 91 | 270 | 265 |
| 1×95 | 10.5 | 1.3 | 2.5 | 2.5 | 51 | 4809 | 0.193 | 91 | 330 | 315 |
| 1×120 | 10.5 | 1.4 | 2.5 | 2.6 | 52 | 5247 | 0.153 | 91 | 375 | 360 |
| 1×150 | 10.5 | 1.4 | 2.5 | 2.6 | 54 | 5663 | 0.124 | 91 | 425 | 400 |
| 1×185 | 10.5 | 1.4 | 2.5 | 2.7 | 55 | 6191 | 0.0991 | 91 | 485 | 455 |
| 1×240 | 10.5 | 1.5 | 2.5 | 2.8 | 58 | 7003 | 0.0754 | 91 | 560 | 525 |
| 1×300 | 10.5 | 1.5 | 2.5 | 2.9 | 60 | 7819 | 0.0601 | 91 | 650 | 595 |
| 1×400 | 10.5 | 1.6 | 2.5 | 3 | 64 | 9051 | 0.047 | 91 | 760 | 680 |
| 1×500 | 10.5 | 1.6 | 2.5 | 3.1 | 67 | 10398 | 0.0366 | 91 | 875 | 775 |
| 3×50 | 10.5 | 1.8 | 3.15 | 3.9 | 92 | 11660 | 0.387 | 91 | 185 | 200 |
| 3×70 | 10.5 | 1.8 | 3.15 | 4 | 96 | 12860 | 0.268 | 91 | 230 | 250 |
| 3×95 | 10.5 | 1.9 | 3.15 | 4.1 | 99 | 14036 | 0.193 | 91 | 285 | 300 |
| 3×120 | 10.5 | 2 | 3.15 | 4.2 | 103 | 15306 | 0.153 | 91 | 310 | 380 |
| 3×150 | 10.5 | 2 | 3.15 | 4.4 | 106 | 16662 | 0.124 | 91 | 360 | 425 |
| 3×185 | 10.5 | 2 | 3.15 | 4.5 | 109 | 18130 | 0.0991 | 91 | 400 | 490 |
| 3×240 | 10.5 | 2 | 3.15 | 4.6 | 114 | 20258 | 0.0754 | 91 | 470 | 555 |
| 3×300 | 10.5 | 2 | 3.15 | 4.8 | 119 | 22517 | 0.0601 | 91 | 540 | 625 |
